WLAN Antenna
| Model/Item No.: | JAT-026 |
| Country of Origin: | Taiwan |
| Sales Method: | Export, Manufacture, OEM/ODM |
| Quantity per Month: | 10000 |
| Packaging Method: | Polybag |
| Payment Terms: | T/T,L/C |
| Delivery Way-Delivery Port: | FOB TAIWAN |
| Delivery Way-Delivery Date: | 4 ~ 5 WEEKS |
|
Product Specifications:
WiFi 2.4GHz antenna
A.Electrical Characteristics
Working Frequency Range 2400 ~ 2500 MHz
4900 ~ 5900 MHz
S.W.R. 2400 ~ 2500 MHz:< 2.0
4900 ~ 5900 MHz:< 2.0
Antenna Gain 2400 MHz: 1.9 dBi ± 0.5dBi
2450 MHz: 1.7 dBi ± 0.5dBi
2500 MHz: 2.2 dBi ± 0.5dBi
4900 MHz: 3.4 dBi ± 0.5dBi
5150 MHz: 3.2 dBi ± 0.5dBi
5350 MHz: 3.1 dBi ± 0.5dBi
5470 MHz: 3.4 dBi ± 0.5dBi
5725 MHz: 2.7 dBi ± 0.5dBi
5900 MHz: 2.7 dBi ± 0.5dBi
Antenna Radiation Pattern Omni-directional
Polarization Linear / Vertical
Admitted Power 1 W
Impedance 50 Ohm
Connector SMA Plug Reverse
White Cover
B.Mechanical Dimension
Total Length 136 mm
C.Material
Color White
Material of Outer Cover TPE (Color: White)
Material of Hinge PC(Color: White)
Material of Base PBT(Color: White)
Material of Connector Copper, Ni plated
Material of Tube Copper
Weight 11.7g
D.Environmental
Operation Temperature - 20˚C ~ + 65˚C
A.Electrical Characteristics
Working Frequency Range 2400 ~ 2500 MHz
4900 ~ 5900 MHz
S.W.R. 2400 ~ 2500 MHz:< 2.0
4900 ~ 5900 MHz:< 2.0
Antenna Gain 2400 MHz: 1.9 dBi ± 0.5dBi
2450 MHz: 1.7 dBi ± 0.5dBi
2500 MHz: 2.2 dBi ± 0.5dBi
4900 MHz: 3.4 dBi ± 0.5dBi
5150 MHz: 3.2 dBi ± 0.5dBi
5350 MHz: 3.1 dBi ± 0.5dBi
5470 MHz: 3.4 dBi ± 0.5dBi
5725 MHz: 2.7 dBi ± 0.5dBi
5900 MHz: 2.7 dBi ± 0.5dBi
Antenna Radiation Pattern Omni-directional
Polarization Linear / Vertical
Admitted Power 1 W
Impedance 50 Ohm
Connector SMA Plug Reverse
White Cover
B.Mechanical Dimension
Total Length 136 mm
C.Material
Color White
Material of Outer Cover TPE (Color: White)
Material of Hinge PC(Color: White)
Material of Base PBT(Color: White)
Material of Connector Copper, Ni plated
Material of Tube Copper
Weight 11.7g
D.Environmental
Operation Temperature - 20˚C ~ + 65˚C
Competitive Advantages:
Well and High Quality Control,OEM Accepted,Prompt Delivery,Customer's Design and Logo are Welcome,Competitive Prices,Earth-friendly Products,Small Order Acceptable,ODM Accepted
