Home > Product List > WLAN Antennas > MIMO Antenna > Car Antenna, GPS Antenna, WLAN Antennas, Mobile Phone Antennas, Antennas for Communications
Car Antenna, GPS Antenna, WLAN Antennas, Mobile Phone Antennas, Antennas for Communications
| Model/Item No.: | JAT-108 |
| Country of Origin: | Taiwan |
| Sales Method: | Export, Manufacture, OEM/ODM |
| Quantity per Month: | 5000 |
| Packaging Method: | white box each |
| Payment Terms: | T/T,L/C |
| Delivery Way-Delivery Port: | FOB TAIWAN |
| Delivery Way-Delivery Date: | 5 ~ 6 WEEKS |
| Minimum Order Quantity: | 100 Piece/Pieces |
|
Product Specifications:
WLAN Antennas, GPS Antennas, GSM Antennas, Car Antennas, Mobile Phone Antennas, WiFi Antennas, Radio Antennas, RF Antennas - all kinds of antennas for communications we have.
GPS & Cellular, LTE, WiFi MULTIBAND Diversity MIMO ANTENNA
*** supports 2G, 3G, 3G+ and 4G technologies including LTE, AMPS, PCS,
GSM, UMTS, AWS, and GPS.
CELLULAR ANTENNA
Frequency: 698-960/1710-2170/2400-2500/4300-6000 MHz
Gain: 2.5 dBi (max)
VSWR: <1.5
Impedance: 50 ohms
Power Supply : Power Handling Capacity: 10 W
GPS ANTENNA
Frequency: 1575.42 MHz
GPS LNA Gain : 27 dB typ
Polarization: R.H.C.P
Impedance: 50 ohms
Noise Figure : 1.5 dB (max)
Band Width : 10 MHz
VSWR : < 1.5
Supply Voltage : DC =3~5V
Consumption : 20mA (max)
Cable, Connector & others
Cable : RG58 (x4), RG174 (x1)
Connector: SMA male (x3), RP SMA male (x2)
Radome Material : ABS
Mounting : magnet base
Operating Temperature: -30℃~ +80℃
GPS & Cellular, LTE, WiFi MULTIBAND Diversity MIMO ANTENNA
*** supports 2G, 3G, 3G+ and 4G technologies including LTE, AMPS, PCS,
GSM, UMTS, AWS, and GPS.
CELLULAR ANTENNA
Frequency: 698-960/1710-2170/2400-2500/4300-6000 MHz
Gain: 2.5 dBi (max)
VSWR: <1.5
Impedance: 50 ohms
Power Supply : Power Handling Capacity: 10 W
GPS ANTENNA
Frequency: 1575.42 MHz
GPS LNA Gain : 27 dB typ
Polarization: R.H.C.P
Impedance: 50 ohms
Noise Figure : 1.5 dB (max)
Band Width : 10 MHz
VSWR : < 1.5
Supply Voltage : DC =3~5V
Consumption : 20mA (max)
Cable, Connector & others
Cable : RG58 (x4), RG174 (x1)
Connector: SMA male (x3), RP SMA male (x2)
Radome Material : ABS
Mounting : magnet base
Operating Temperature: -30℃~ +80℃
Competitive Advantages:
Well and High Quality Control,OEM Accepted,Prompt Delivery,Customer's Design and Logo are Welcome,Competitive Prices,Earth-friendly Products,Small Order Acceptable,ODM Accepted
Keywords:
GPS Antenna,Antennas for Communications,Car Antenna,GPS GSM Combo Antenna,Car Electronics
