Sim Card Connector
| Model/Item No.: | JSI-727 |
| Country of Origin: | Taiwan |
| Sales Method: | Export, Manufacture, OEM/ODM |
| Quantity per Month: | 5000000 |
| Packaging Method: | standard package |
| Payment Terms: | T/T,L/C |
| Delivery Way-Delivery Date: | 1 ~ 2 weeks |
| Minimum Order Quantity: | 2000 Piece/Pieces |
|
Product Specifications:
1. General Characteristics
Dimensions: 15.85LX16.50WX3.00H mm
Weight : Approx 0.70 ± 0.2g
Durability: 5,000 cycles min.
2. Electrical Characteristics
Contact resistance : 50m Ω typical, 100m Ω max
Insulation resistance : >1000M Ω / 500V DC
3. Solderability
Vapor phase : 215℃, 30sec. Max
IR reflow : 250℃, 5sec. Max
Manual soldering : 370℃, 3sec. Max
4. Environmental Characteristics
Operation temperature : -40 ℃ ~ + 85℃
Operationg humidity : 10% ~ +95%RH
Dimensions: 15.85LX16.50WX3.00H mm
Weight : Approx 0.70 ± 0.2g
Durability: 5,000 cycles min.
2. Electrical Characteristics
Contact resistance : 50m Ω typical, 100m Ω max
Insulation resistance : >1000M Ω / 500V DC
3. Solderability
Vapor phase : 215℃, 30sec. Max
IR reflow : 250℃, 5sec. Max
Manual soldering : 370℃, 3sec. Max
4. Environmental Characteristics
Operation temperature : -40 ℃ ~ + 85℃
Operationg humidity : 10% ~ +95%RH
Competitive Advantages:
Well and High Quality Control,OEM Accepted,Prompt Delivery,Customer's Design and Logo are Welcome,Competitive Prices,ODM Accepted
Keywords:
connector,electrical parts,Sim Card Connector,Sim Card Socket,Sim Card Slot
