Home > Product List > WLAN Antennas > Swivel Antenna > WLAN  Antenna

WLAN Antenna

Model/Item No.: JAT-026
Country of Origin: Taiwan
Sales Method: Export, Manufacture, OEM/ODM
Quantity per Month: 10000
Packaging Method: Polybag
Payment Terms: T/T,L/C
Delivery Way-Delivery Port: FOB TAIWAN
Delivery Way-Delivery Date: 4 ~ 5 WEEKS

Product Specifications:

WiFi 2.4GHz antenna
A.Electrical Characteristics
Working Frequency Range 2400 ~ 2500 MHz
4900 ~ 5900 MHz
S.W.R. 2400 ~ 2500 MHz:< 2.0
4900 ~ 5900 MHz:< 2.0
Antenna Gain 2400 MHz: 1.9 dBi ± 0.5dBi
2450 MHz: 1.7 dBi ± 0.5dBi
2500 MHz: 2.2 dBi ± 0.5dBi
4900 MHz: 3.4 dBi ± 0.5dBi
5150 MHz: 3.2 dBi ± 0.5dBi
5350 MHz: 3.1 dBi ± 0.5dBi
5470 MHz: 3.4 dBi ± 0.5dBi
5725 MHz: 2.7 dBi ± 0.5dBi
5900 MHz: 2.7 dBi ± 0.5dBi
Antenna Radiation Pattern Omni-directional
Polarization Linear / Vertical
Admitted Power 1 W
Impedance 50 Ohm
Connector SMA Plug Reverse
White Cover

B.Mechanical Dimension
Total Length 136 mm

C.Material
Color White
Material of Outer Cover TPE (Color: White)
Material of Hinge PC(Color: White)
Material of Base PBT(Color: White)
Material of Connector Copper, Ni plated
Material of Tube Copper
Weight 11.7g

D.Environmental
Operation Temperature - 20˚C ~ + 65˚C
